KETTWIESEL ALLROUND recumbent trike – engineered for cornering fun
The one-of-a-kind “KETTWIESEL feeling” comes from its go-kart agility and tight turning circle.
The entry-level model for the HASE fun class and the chassis for many adaptive trikes
The KETTWIESEL ALLROUND delta recumbent trike lets you experience all the perks and practicality of triking. With its unrivaled cornering stability, high level of safety, and exceptional comfort, the KETTWIESEL offers unparalleled riding fun. And: at stoplights and during breaks, you can relax in your seat while other cyclists dismount.
It’s easy to understand why this spirited roadster is also the perfect chassis for many of our adaptive vehicles and hand bikes. The KETTWIESEL was designed to offer an ideal blend of ergonomics, sportiness, and unlimited versatility.
Perfect adaptability to the rider’s height and weight
The under-seat handlebars of the KETTWIESEL complement its ergonomics. By loosening an Allen bolt, the angle and lateral positioning of each handlebar can be precisely adjusted to the rider and sitting position.
Thanks to the quick-adjust frame, the front boom can be easily and accurately repositioned to suit the rider’s leg length without having to shorten or lengthen the chain. The length-adjustment markings make it easy to remember length settings when switching between various riders.
Any sitting position is possible
Thanks to the handy quick-release levers, adjusting the angle of the seatback is child’s play. Choose any sitting position: from laid-back and sporty to upright. For transport, just release the seatback to make the trike flat for easy stowing.
Easy wheel removal with QUICKSTICK hubs
If you need to take off the wheels for storing or transporting the KETTWIESEL recumbent trike, then simply loosen the bolt on each QUICKSTICK hub – and they’re off!
- Very agile, smooth-riding
- Excellent safety and stability thanks to low center of gravity
- Space saving when parked on end
- Usable in tandem and as a trailer
- E-motor option
|Total length||63″-81″ (160-205 cm), without front wheel 54″ (137 cm)|
|Total width||34″ (86 cm)|
|Total height||31″ (80 cm), with seat folded down: 21″ (53 cm)|
|Turning circle||left 10’10” (3.30 m), right 11’6″ (3.50 m) at mean length adjustment|
|Seat height||34″ (48 cm)|
|Bottom bracket height||19″ (48 cm)|
|Pack size||63″-81″×21″x34″ (160-205x53x86 cm)|
|Wheelbase||46″-64″ (116-162 cm)|
|Front boom||6061-T6 aluminum|
|Max. load||308 lb (140 kg)|
|Brakes||Avid BB7 mechanical disc brakes with parking brake lever|
|Wheels||20″, Hubs: HASE BIKES Quickstick (rear), Rims: double wall with eyelets, Spokes: Sapim, Tires: Schwalbe Marathon 47×406|
|Gears||HASE BIKES LINEAR 11-speed|
|Crankset||Truvativ Touro 52 tooth|
|Frame Colors||Matte Red, Matte Black, Matte Yellow|
|Fenders||SKS black matte|
|Weight||43 lb (19.5 kg)|
|Speeds||9 or 27|
|Optional||Differential, battery lights|
